Description of radio control system
mc
-22s
Expandable radio control system for up to 10 control functions (PPM24: 12 functions)
• World’s fi rst: four-language dialogue menu (Ger-
man, English, French, Italian)
• The latest hardware and integral Synthesizer sys-
tem for channel selection, with security menu to
prevent switching the transmitter on accidentally
• Up to twelve control functions (PPM24)
• Simplifi ed assignment of transmitter controls such
as control sticks, external switches, proportional
controls, trim levers as transmitter controls
• 30 model memories
• 3D rotary encoder in conjunction with four pro-
gramming buttons for accurate adjustment and ex-
cellent programming convenience
• MULTI-DATA high-resolution GRAPHIC LCD
screen provides superb monitoring facilities, ac-
curate graphical representation of multi-point cur-
ves for throttle, collective pitch, tail rotor etc., plus
EXPO / DUAL RATE functions and mixer curves
• CONVENIENT MODE SELECTOR allows easy
switching between stick modes 1 to 4 (e.g. throttle
right / throttle left)
• Real Time Processing (RTP). All selected settings
and changes take immediate effect at the receiver
output, virtually in real time
• ADT Advanced Digital Trim system for all four stick
trim functions, with easily variable throttle / idle
trim and variable trim increment
• Four switchable types of modulation:
PPM 18
The most widely used standard transmission pro-
cess (FM and FMsss).
For C 6, C 8, C 12, C 16, C 17, C 19, DS 18, DS
19, DS 20 receivers, and XP 4, XP 8, XP 10, XP
12, XN 12, XM 16, R16SCAN, R 600 light, R 600,
R 700, C 6 FM, SB6 SYN 40 S, SR6SYN miniatu-
re receivers
Professional high-technology micro-computer ra-
dio control system. Ultra-speed low-power single-
chip micro-computer with 256 kByte (2 Mbit) fl ash
memory, with 16 kByte (128 kbit) RAM, 73 ns com-
mand cycle!
With integral high-speed precision A/D converter
and proven, highly practical dual-function rotary
encoder and 3D rotary select programming tech-
nology.
