8
Description of radio control system
PPM24
PPM multi-servo transmission mode for simultane-
ous operation of up to twelve servos. For the DS
24 FM S receiver
PCM 20
PCM with system resolution of 512 steps per con-
trol function. For mc-12, mc-20, DS 20 mc recei-
vers.
SPCM 20
Super PCM modulation with high system resoluti-
on of 1024 steps per control function.
For smc-14 S, smc-16 SCAN, smc-19, SMC-19
DS, smc-20, smc-20 DS, smc-20 DSYN, smc-20
DSCAN receivers
• Six freely programmable mixers for fi xed-wing mo-
dels and helicopters, of which two in each case
are fi ve-point curve mixers, freely variable in 1%
increments. An ingenious polynomial approximati-
on process is applied, generating an ideally roun-
ded curve based on your selected mixer reference
points.
• The fi ve-point throttle and collective pitch cur-
ves available in the helicopter menu also feature a
multi-point curve system (MPC). An ingenious po-
lynomial approximation process is applied, gene-
rating an ideally rounded curve based on your se-
lected mixer reference points.
• Two-stage Expo / Dual Rate system, individually
variable, switchable in fl ight, separately variable for
each model
• Helicopter swashplate mixers for 1, 2, 3 and 4-
point linkages
• Integral fl ight phase menus, sub-trim for neutral
point adjustment of all servos, aileron differential
mixer, butterfl y (crow) mixer, fl aperon mixer
• Graphical servo display provides a fast, straightfor-
ward overview for checking servo settings
• Servo travel limiting for all servo channels, variab-
le separately for each end-point (single-side servo
throw)
• Programmable fail-safe function with variable time
hold or pre-set function (PCM and SPCM only)
• Stop-watch / count-down timers with alarm func-
tion
• Operating hours timer, available separately for
each model
• HELP button provides valuable hints on program-
ming and the currently selected programming
menu
• Model copy function for all model memories
• Prepared for an interface module for copying bet-
ween two mc-22s transmitters, mc-22 / mc-22s, or
between mc-22s and PC
• Two NAUTIC modules and decoders can be con-
nected for function expansion: each NAUTIC mo-
dule expands one receiver output to form eight
switched channels or four proportional functions.
• Prepared for use as Pupil or Teacher transmitter in
a Trainer system
• Non-volatile memory for data back-up even with
transmitter battery removed or completely dischar-
ged
mc
-22s
Expandable radio control system for up to 10 control functions (PPM24: 12 functions)
