Alternatively, the transmitter mz-10 HoTT can be equipped with a
firmware version suitable for the operation of copters. See section
"Firmware Updates" on the last pages of this manual for more infor-
mation.
mz-10
7
5
1
2
3
4
6
8
97
10
11
12
13 14
1 antenna integrated in the case
2 Eyelet for neck strap
3 Switch between Attitude and Rate mode
4 FLIP / OFF / LED
5 Right-hand control stick
6 ARROW button
7 Trim - active in Attitude mode only
8 ON/OFF switch
9 LED indicators field
10 MODE button
11 Left-hand control stick
12 Switch normal use / motor stop
13 Carrying handle
14 Central status LED
