Use mode selection
Normal mode
Teacher mode
Pupil mode
To change the use mode, move the "TRAINER" switch in the desired
position with the transmitter in switched off, push and hold the
MODE button and switch subsequently the transmitter on.
• The last selected model settings, control mode so as an eventu-
ally set receiver binding remain unchanged. The binding of a
receiver is however possible only in "NORMAL" mode.
• The use of a model in teacher or pupil mode is only possible in
connection with the Trainer system.
• After every activation of the "NORMAL" use mode:
ശ The transmitter will be in program mode "Fail safe".
ശ The buzzer beeps each 2 seconds and contemporary the sta-
tus LED blinks.
ശ The country setting, even if changed to "FRANCE", will be set
to "GENERAL" so as the position of the digital trim will be set
to "neutral".
ശ The warning threshold for transmitter battery will be set to
4,5 V, as long this has been changed through the optional
SMART BOX.
If the fail safe settings saved in the receiver have to be retained,
switch the transmitter off and after a short pause again on. Other-
wise proceed as described in "Fail safe".
Note
The mz-10 HoTT transmitter remains after a conversion of the con-
trol mode in the last selected use mode until this will be changed.
This is completely independent from the occurred setting of the
TRAINER switch and even after switching on again the transmitter.

GRAUPNER MZ-10 HOTT Specifications

General

Modulation	FHSS
Proper use	Airplane, Aircraft
Product type	Remote control
Product color	Black
Antenna length	120 mm
Frequency band	2.4 - 2.4835 GHz
Menu languages	German
Channels quantity	5 channels
Brand compatibility	Any brand
Number of memory records	1
Maximum operating distance	4000 m
Manual	Yes
Operating temperature (T-T)	-10 - 55 °C
Battery type	AA
Number of batteries supported	4
Built-in display	No

Weight and Dimensions

Depth	184 mm
Width	259 mm
Height	96 mm
Weight	630 g
