GRAUPNER MZ-10 HOTT

30 / 48
S1042_sh_V1
Due to the different installation of the servos and rudder linkages in
the model, the direction for certain servos can be reversed.
In a V-tail:
Servo with wrong direction of
rotation
Solution
Reversed rudder and elevator Change servo 3 + 4 direction
The rudder is correct and the
elevator is reversed
Switch servos 3 + 4 on the
receiver
Elevator correct, rudder reversed Change servo 3 + 4 direction
and switch them in the
receiver
In delta wing or flying-wing
Servo with wrong direction of
rotation
Solution
The elevator and aileron are
reversed
Change servo 2 + 3 direction
The elevator is correct and the
aileron is reversed
Change servo 2 + 3 direction
and switch them in the
receiver
The aileron is correct and the
elevator is reversed
Switch servos 2 + 3 on the
receiver
Transmitter programming
!
CAUTION
Safely interrupt the fuel line or the power supply in your model,
so that during the programming the motor cannot start acciden-
tally.
Notes
• Within an activation of the described below rotation procedure
for setting the desired State and control arrangement, however,
only one option can always be activated. For a second setting,
the rotation procedure again must be recalled.
• The country and control mode options can be selected in each
of the three operating modes (NORMAL, TEACHER, PUPIL).
