Firmware update
Firmware updates of the transmitter are carried out via the back
DATA port using a laptop or PC with Windows 7 ... 10. You will also
need a USB interface, order no. 7168.6, and adapter lead, order no.
7168.6A or 7168.S, which are available separately.
The programs and files required can be found in the Download area
for the corresponding products at www.graupner.de.
Download this software package from the Internet, and unpack it on
your computer. All other information can be found in Internet in the
same page where the software package is available.
Connect the adapter lead to the USB interface. The polarity of the
plug-in system cannot be reversed. Note the small chamfers on the
sides. Do not use force, the plug should click into place easily.
The update is carried out via the "HoTT device" program section of
the program "Firmware_Upgrade_gr_Studio". Please follow the
notes of the software. The further procedure is also described in
detail in the manual contained in the data package. You can also
download these from the download page of the product at
www.graupner.de.
Transmitter software update
Perform update step by step
• Before each update check the transmitter battery charge status.
Connect the interface through the included USB cable to a PC.
• Do not disconnect the link to the computer during an update!
Make sure that the link between the transmitter and computer
is operational.
• Plug the other end of the adapter cable into the jack marked
"DATA" on the back of the transmitter. Make sure that the orange
cable is plugged into the left, marked as "S", and the brown or
black cable on the right PIN marked with a "-". Do not apply force.
The plug should be fully inserted.
• Select "Auto download" or "Open file" to select between the cur-
rent firmware versions.
• Select the file "mz-10_ ... bin" if you want to keep the default
firmware or to return to it or the file "MZ-10C_ ... bin" for the
copter version.
