Connections and fixtures
Attaching the transmitter neck-strap
On the upper side of the transmitter there is an eyelet which can be
used to hook a neck-strap.
Socket "DATA / S + -"
For the socket "DATA / S + -“ there are 3 possible connection options:
1. With the optionally available SMART-BOX, allows the use of other
HoTT functions
2. With the optionally available USB adapter, allows the connection
between transmitter and PC for a firmware update
3. With the optionally available Bluetooth module allows the trans-
mission of telemetry data to a compatible smartphone or tablet.
Note for the polarity of the socket "DATA / S + -“:
S = signal line (orange)
+ = Plus line (red)
- = Minus line (brown or black)
You can find more information about the listed accessories on
www.graupner.de.
Digital trim with an acoustic feedback
The two control sticks have digital trimming. Briefly touch the trim-
ming switch to move the neutral position of the control stick by a
specific value with each click. If it is held, the trimming moves in the
corresponding direction with increasing speed.
The adjustment is made "audible" by tones of varying levels. It is
therefore easy to find the middle position during the use of the
model. If you go past the middle position, a brief pause is inserted.
The trim positions are automatically saved.
The digital trim reacts to a trim lever movement only if the transmit-
ter is switched on.
Note
In the copter version, the digital trim is effective only in the front
switch position of the Attitude/Rate mode changeover switch (3)
mounted on the right upper side of the transmitter housing.
