Sensors eventually installed in the model have to be connected to
this receiver, because the transmitter will indicate only the values
coming from the back channel of the last bound receiver. All other
receiver work in parallel to the last receiver bound to the transmit-
ter.
Attention
If one of these "last but not least" connected receivers is to be used
as the main receiver, this receiver has to be reconnected as "last"
receiver. Otherwise the LED of the receiver signals correct reception
and the servos react to control commands, but there is still no
telemetry connection. Also, neither the range and function test
described below nor the correct range warning is carried out.
Range and function test
When the range test starts, through contemporaneously pushing
the left MODE and the right arrow keys, the transmitter output
power decreases significantly, then you can perform a function test
in a distance not higher than 100 m. After the 90 second range test,
the transmitter switches back to full output, and the signal tone
stops. You can always interrupt the range test by pushing for approx-
imately 1 - 2 seconds the MODE and the arrow buttons.
It is useful to have an assistant who helps you.
Note
The range test works only with the last bound receiver. Only with it
there is a feedback channel for the telemetry connection.
Range test step by step
1. Install the already bound receiver in the model.
2. Place the model on a flat surface (cement, mowed lawn or
ground) so that the receiver antennas are at least 15 cm above
the ground. It may therefore be necessary to place a support
underneath the model during the test.
3. Switch the transmitter on and wait until the receiver indicate
according to the manual a correct function connection. Only now
the servos can be moved.
4. Hold the transmitter at hip level at a slight distance from your
body.
