GRAUPNER MZ-10 HOTT User Manual

42 / 48
S1042_sh_V1
T/S mode
Note
Before starting trainer mode for the operational model, be sure to
check whether all the functions have been correctly transferred.
In the canter switch position ("TEACHER") of a teacher's transmitter
mz-10 HoTT the teacher's transmitter controls all control functions.
In the upper, self-centering, switch position ("PUPIL"), the pupil can
control the model as long as the switch is held by the teacher in this
position.
During the training mode teacher and pupil can maintain a comfort-
able distance. The so-called call range (max. 50 m) should not be
exceeded. Nor should there be any other persons between teacher
and student. These can affect the range of the return channel used
for connecting the two transmitters. In such a case you should pro-
vide a smaller distance between both transmitters. If it does not
help, you should immediately stop the use of the model and search
for the reason.
!
WARNING
The teacher transmitter should never be switched off during the
use! Without teacher transmitter the model cannot be controlled.
In case that during the control by the pupil transmitter the con-
nection to this transmitter is interrupted, the TRAINER switch on
the mz-10 teacher transmitter has to be moved as soon as possible
again to the "TEACHER" position, so that the transmitter can take
back the control of the model. Other teacher transmitters take in
such a case automatically the control of the model.
Switch functions
Motor stop function
The motor stop function is active completely independently from
the position of this switch, until after switching on the transmitter
the throttle/pitch stick has not been brought at least once in the
motor-OFF position.
!
ATTENTION
This function prevents accidental starting of motors, thus reducing
the risk of accident. For safety reasons you should get the attitude
to move the motor-off switch forward only when the start is very
imminent and you should move it backward as soon as you have
landed your model.
Motor control
Motor cut-off

GRAUPNER MZ-10 HOTT Specifications

General

Modulation	FHSS
Proper use	Airplane, Aircraft
Product type	Remote control
Product color	Black
Antenna length	120 mm
Frequency band	2.4 - 2.4835 GHz
Menu languages	German
Channels quantity	5 channels
Brand compatibility	Any brand
Number of memory records	1
Maximum operating distance	4000 m
Manual	Yes
Operating temperature (T-T)	-10 - 55 °C
Battery type	AA
Number of batteries supported	4
Built-in display	No

Weight and Dimensions

Depth	184 mm
Width	259 mm
Height	96 mm
Weight	630 g
