35 / 48
S1042_sh_V1
"2AILE"
For models with 2 aileron servos.
By aileron actuation the servos connected to the outputs 2 and 5
work in parallel. The aileron trim acts on both servos.
Note
A conversion of "CH5" has in this case no effect.
"DELTA"
For delta and flying-wing model with one servo each wing.
The aileron and elevator control are carried out through the servos
connected to the channels 2 and 3. The mixer for ailerons and ele-
vator are actuated by the transmitter. The aileron and elevator trim
acts on both servos.
"V-TAIL"
For models with V-tail and 1 or 2 aileron servo.
The elevator and rudder are controlled by two separately-articulated
rudders arranged in a V-shape connected to channel 3 and 4. The
mixer for rudder and elevator is actuated by the transmitter. The
rudder and elevator trim acts on both servos.
The related active setting will be indicated after the transmitter
switch-on for about five seconds through the LED field on the trans-
mitter.
Programming step-by-step
1. Switch on the transmitter without programming connector.
These options can be selected in each of the three operating
modes (NORMAL, TEACHER, PUPIL).
2. Press the arrow button to the right of the LED field for at least 2
seconds.
After releasing, a short beep will be heard and the CH1 LED in the
"REVERSE" LED line flashes.
3. Press the arrow button to the right of the LED field until the LED
of the desired option flashes.
Between the seven possible setting options CH1 ... CH5, 2AILE
and DELTA is changed in the rotary process.
(The LEDs of options CH1 ... CH5 flash red, the LEDs of options
2AILE and DELTA are green.)
4. To change the status of the desired option push the MODE but-
ton.
The blinking LED lights solid on.
5. Use the arrow button to the right of the LED field to move to the
next option and change the next option.
6. You can always interrupt exit this menu by pushing for at least 2
seconds the arrow button.
