7.3 HYDRAULIC HOSES
NOTE: When loosening or tightening any hydraulic
hoses, use the correct wrench. If hoses are to be dis-
connected or reconnected at a fitting use two
wrenches, one on the hose and one on the fitting, to
prevent damage by twisting off the fitting.
Figure 51
1. Power Steering Unit
2. Sleeve, 12"
3. RH Ball Socket
4. Steering Cylinder
5. LH Ball Socket
1
2
3
4
5
PF0533
