NOTICETECHNIQUEGAMMEM40
M40RANGETECHNICALMANUAL
Date:June2009From
AftersalesTechnicalSupport
Ref.M40GB/FF‐Vers.1.0
Page - 5
Part number
/ References
Designation / Désignation
Initial stock for 20
machines sold /
Stock recommendé pour
20 vendues
41258 ELECTRONICPROTECTIVECOVER
41265 VICEMOTORBELTGTM40 1
41266 MAINWIRINGLOOMGTM40
41269 FLATKEYBOARDEXTENSIONFORGTM40COM1LINK 2
41270 MICROSWITCHWITHCONNECTOR 2
41272 FANFILTER
41274 POWERBOARDM40&IM4 1
41278 CYL.ATT.BOARDGTM40
41279 VICEMOTORCABLED230V
41280 VICECABLEDMOTOR110V
41281 TIGHTPUMPSWITCHGTM40
41847 110VCYL.ATTCH.GIFTWITHVICEMOTOR
41975 CYL.ATTJAWRAISERBLOCKM40
42010 ZMOTORCOVERGTM40 2
42043 LUBRICATIONPIPE
42065 KEYBOARDPROTECTIVEGTM40
42115 Std.Exc.UCBOARDIM4GTM40
42116 Std.Exc.PUIBOARDIM4GTM40
42162 PROTECTIVEFOAMGTM40 1
42184 M40REDPOINTERKIT‐OLDMODEL 3
45465 STEPPERMOTOR 1
45466 STEPPERMOTOR 1
45619 PINONANDPERPETUALSCREW 1
45646 Std.Exc.ELECTRONICCASEGTM40KIT
45698 USB2.0CABLE2M 1
45757 ELECTRONICCASEGTM40KIT‐COM1
45758 FITTEDFANGTM40 1
45759 YLEADSCREWKITGTM40 2
45760 X,YCOUPLINGIS20097 1
45761 XLEADSCREWKITGTM40 2
45770 CARRIAGEZWITHOUTTHE2MOTORS
45771 FITTEDCUTTERBUTTONDIAM.4.36
45772 ZAXISCOUPLINGGTM40 1
45773 GTM40DIODEKIT 2
45774 SPINDLECOVERFITTEDGTM40
45948 CYL.ATT.MOTORANDJAWKITWITHOUTBOARD
46473 M20/M40USBSIRIUSBOARD 2
46479 SPINDLEMOTORBOARDM20
46673 DEEPVICEKIT
47008 DRIVERBOARDFORCYLIND.ATT.M40&M40G 1
47399 CYL.ATTAC.STEPPERMOTORWITHSILICON
47592 MINIDIN/DINADAPTATOR
47600 24VRELAY 1
47603 Std.Exc.MONO‐BOARDUSBGTM20/GTM40
47668 ELECTRONICCASEGTM40USBKIT
47698 CYLINDERATTACHMENTBOARDMEPB 2
