94
5.6.6 Networking and Wiring between Units
Notes
(1)As shown in the diagram above, CN33 and CN25 of all modules are connected by a
three-core four-pin shielded communication line whose ground wire will be linked to the
terminal near the main board.
A Series Modular-type Air-cooled (Heat Pump) Chiller
