Gree FLEXX Series Service Manual

GREE DC INVERTER HEAT PUMP CONDENSING UNIT
20
No.
Printing
Interface
No.
Printing
Interface
6
VA
Electromagnetic valve
interface
16
COM7
Unit communication interface
7
FA
Electronic expansion valve
interface
17
CN6
GPRS communication interface
8
FA1
Electronic expansion valve 1
interface
Refrigerant heat dissipation
18
COM-MANUAL
Thermostat interface
9
COMM1
Drive communication
interface
19
DC_MOTOR1
DC_MOTOR2
DC motor output
10
L-PRESS
Low pressure sensor
interface
20
PWR1
310V DC power supply interface
Drive Board:
Model:
FLEXX36HP230V1AO
No.
Printing
Interface
No.
Printing
Interface
1
L2-2
PFC induction wire (blue)
10
P-OUT
Reserved
2
AC-L
Live wire
11
L1-2
PFC induction wire (white)
3
L1-1
PFC induction wire (brown)
12
L2-1
PFC induction wire (yellow)
4
N
Neutral wire
13
G-OUT
Reserved
5
COMM1
Communication terminal, same with
COMM
14
U
Compressor U phase terminal
8
⑩
9
⑩
10
⑩
13
⑩
1
⑩
2
⑩
3
⑩
4
⑩
5
⑩
6
⑩
7
⑩
11
⑩
12
⑩
17
⑩
14
⑩
15
⑩
16
⑩

Gree FLEXX Series Specifications

General

Type	Heat Pump
Series	FLEXX
SEER	Up to 20
HSPF	Up to 10
Refrigerant	R410A
Heating Operation Range	-22°F to 75°F
Cooling Operation Range	5°F to 122°F
Operating Temperature Range (Heating)	-22°F to 75°F
Operating Temperature Range (Cooling)	5°F to 122°F
Energy Efficiency Ratio (EER)	Up to 12.5
Dimensions (Outdoor Unit)	Varies by model
Weight (Outdoor Unit)	Varies by model
Compressor Type	Inverter
Power Supply	208/230V, 1Ph, 60Hz
Noise Level	As low as 55 dB(A)
