GREE DC INVERTER HEAT PUMP CONDENSING UNIT
79
Model: FLEXX36HP230V1AO
Removal of condenser
NOTE:Before removing the condenser, make sure there is no refrigerant in the pipeline and power is cut off.
Step
Work instruction
1. Remove the panels.
 Remove the upper, lower and
front panels.
2. Remove the electric box.
 Loosen the wire clamp at the
bottom of the electric box.
 Unscrew the screws of electric
box.
 The connection wires inside
and outside the electric box
should be removed.
3. Remove motor support.
 When removing the motor
support, be careful to protect
the components.
