GREEN INSTRUMENTS Maritime G6100 User Manual

Specifications
Page 10 of 111
2 Specifications
Water Monitoring System (WM)
Function
Provides a monitoring/logging system which is fully
compliant with IMO regulations MEPC. 259(68)
Electrical Specification
Please refer to the Electrical Drawings
Display
4” TFT LCD color display
External Communication
Modbus TCP/IP
Optional: Modbus RTU (RS-485) via converter
To be specified upon order
Connections
Refer to the P&ID and the Installation Layout
Recommended Sample Flow
1…6 l/m (Integrated flow sensor detects sample flow)
Sample Pressure
Max 3 bar (g)
Sample Temperature
0…50
o
C
Sample Purity
Particle size of max. 2 mm
Sample Condition
Avoid air and particles in the sampling system
Sample pH Limits
4…11 pH limit
Max Ambient Temperature
Class A (55 °C)
Humidity
Class B
Vibration
Class A
EMC
Class A
Enclosure & Material
Class B (IP54) AISI 1008 Painted
Dimensions & Weight
Refer to the Installation Layout
Supports Sensor Modules: G6110 - G6111 - G6120 - G6130
Sensor Modules
PAH Module – Type G6110/G6111
Legislation
Compliance towards MEPC. 259(68) has been
demonstrated under the surveillance of various class
societies.
