Troubleshooting

Page 66 of 111

Trouble

Possible Cause

Action

Hose pump: Pump hose

pulled into the pump

housing

Too high inlet pressure

Pump hose filled with

deposits

Flange insufficiently

tightened

Insufficient grease

Reduce inlet pressure

Clean or replace the pump hose.

Retighten flange

Top lubricant

The pump does

not start up

Insufficient motor

performance

Power supply incorrection

Blockage in the pump

Check motor and replace if necessary.

Check power supply. Start occurs at a

minimum of 10 Hz.

Check if the suction or discharge side

is blocked. Remove blockage

12.2 PAH

Note

For system serial numbers below 103000 the PAH module interacts with the control

and monitor unit via a 4…20 analog input.

• A G6110 module does not support any means of diagnostics via the 4…20 mA

signal.

• A G6111 supports the following means of diagnostics via the 4…20 mA signal –

Figure 12-1.
