GREEN INSTRUMENTS Maritime G6100 User Manual

Water Monitoring System
Ver.5.0.1 – Revision August 2022 Page 13 of 111
Pump Cabinet – WMP
Equipment
20 mesh strainer, Flow Regulating Valve, Pump
Debubbler, and Manometer
Connections
Refer to the PI diagram & the Installation Layout
Electrical Connections
Refer to the Electrical Drawings
Sample Temperature
0…50
o
C
Sample Purity
Particle size of max. 2 mm
Sample Condition
Avoid air and particles in the sampling system
Pump Lifting Height
Type A
Type B
Lifetime reduces if pressure is above recommendation.
Recommendation: 0.8…1.5 bar (g)
Recommendation: 0.8…2.2 bar (g). Do not exceed 3 bar
Inlet Suction Pressure
Ensure positive suction pressure (0.1…0.8 bar (g))
Dimensions & Weight
Refer to the Installation Layout
Wetted Materials
AISI 316, Acetal, PTFE, PVDF, PMMA.
Impeller materials: NBR (other materials upon request)
Enclosure Material
AISI 304 Painted or Polycarbonate
Hose Pump Cabinet – WMPH
Equipment
20 mesh strainer, Flow Regulating Valve, External Hose
pump, Debubbler, and Manometer
Connections
Refer to the PI diagram & the Installation Layout
Electrical Connections
Refer to the Electrical Drawings
Sample Temperature
0…50°C
Sample Purity
Particle size of max. 2 mm
Sample Condition
Avoid air and particles in the sampling system
Pump Lifting Height
Note: lifetime reduces if pressure is above
recommendation
Recommendation: 0.8…2 bar (g). Do not exceed 3 bar
Inlet Suction Pressure
Ensure positive suction pressure (0.1…0.8 bar (g))
Dimensions & Weight
Refer to the Installation Layout
Wetted Materials
AISI 316, Acetal, PTFE, PVDF, PC, NBR-Nitrile
