Water Monitoring System

Ver.5.0.1 – Revision August 2022 Page 79 of 111

Part No.

Part Description

The specific appearance of the spare parts is

subject change without notice; the function

however will not change

02410

Isolation Amplifier Passive Output

G6110 PAH Module

02221

PAH Sensor Low Range

02223

PAH Sensor High Range

03550

PAH Sensor Dual Range

0-100/800 µg/l

03443

PAH Sensor 0-100 µg/l Reconditioned

Only available if returning used PAH

Sensor

03444

PAH Sensor 0-800 µg/l Reconditioned

Only available if returning used PAH

Sensor

03551

PAH Dual Range Sensor

0-100/800 µg/l Reconditioned

Only available if returning used PAH

Sensor

02529

O-ring PAH Chamber

(2 pcs needed for overhaul)

Figure 1-1: Program Menu Structure of the Water Monitoring System2
