Model G1033/X/Z (Mfd. Since 02/19)
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
G1033/G1033Z Main Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P1033001 HEADSTOCK CASTING 56 P1033056 DUST PORT 5"
2 P1033002 SET SCREW M10-1.5 X 12 57 P1033057 RETURN ROLLER BRACKET
3 P1033003 CUTTERHEAD 20" 4-KNIFE 58 P1033058 RETURN ROLLER
4 P1033004 COMPRESSION SPRING 0.6 X 5.9 X 16 59 P1033059 CAP SCREW M6-1 X 16
5 P1033005 20" PLANER KNIVES-SET OF 4 60 P1033060 WORM GEAR HOUSING
6 P1033006 CUTTERHEAD GIB 61 P1033061 CAP SCREW M6-1 X 50
7 P1033007 HEX BOLT M8-1.25 X 10 62 P1033062 WORM SHAFT
8 P1033008 KNIFE-SETTING JIG ASSEMBLY 63 P1033063 BALL BEARING 6201-2RS
8-1 P1033008-1 E-CLIP 9MM 64 P1033064 INT RETAINING RING 32MM
8-2 P1033008-2 KNIFE-SETTING JIG FOOT 65 P1033065 KEY 4 X 4 X 10
8-3 P1033008-3 KNIFE-SETTING JIG SHAFT 66 P1033066 HANDWHEEL TYPE-2 200D X 12B-K X 3/8-16
12 P1033012 BALL BEARING 6206-2RS 67 P1033067 FLAT WASHER 12MM
13 P1033013 KEY 8 X 8 X 36 68 P1033068 REVOLVING HANDLE 1 X 3-9/16, 3/8-16 X 1/2
14 P1033014 CUTTERHEAD PULLEY 69 P1033069 SCALE
15 P1033015 FENDER WASHER 8 X 30 X 4MM 73V2 P1033073V2 DRIVE CHAIN COVER V2.05.18
16 P1033016 SET SCREW M6-1 X 12 75V2 P1033075V2 GEARBOX COVER PLATE-A V2.05.18
18 P1033018 INFEED ROLLER 77V2 P1033077V2 GEARBOX COVER PLATE-B V2.05.18
19 P1033019 BUSHING BLOCK 78V2 P1033078V2 CAP SCREW M8-1.25 X 10 V2.05.18
20 P1033020 COMPRESSION SPRING 3.5 X 19.7 X 70 79 P1033079 PULLEY GUARD
21 P1033021 TENSIONING SET SCREW M22-1.5 X 20 80 P1033080 STANDOFF-HEX DE
22 P1033022 BUSHING BLOCK PLATE 81 P1033081 FLAT WASHER 5/16
23 P1033023 HEX BOLT M8-1.25 X 30 82 P1033082 HEX NUT 5/16-18
24 P1033024 SET SCREW M6-1 X 16 83V2 P1033083V2 V-BELT M58 3L580 V2.05.18
25 P1033025 HEX NUT M6-1 THIN 84 P1033084 PULLEY COVER
30 P1033030 OUTFEED ROLLER 85 P1033085 KNOB 5/16-18, D1-3/4, ROUND
32 P1033032 CHIP BREAKER PIVOT ROD M12-1.75 X 25 86 P1033086 SWITCH BRACKET (G1033)
33 P1033033 EXT RETAINING RING 12MM 86 P1033Z086 SWITCH BRACKET (G1033Z)
34 P1033034 CHIP BREAKER 87V2 P1033087V2 MAGNETIC SWITCH ASSY SDE MP-18 V2.05.18
35 P1033035 HEX NUT M12-1.75 87V2 P1033Z087V2 MAGNETIC SWITCH ASSY SDE MP-30 V2.05.18
36 P1033036 FLAT SPRING 84 X 46 X 0.6MM 87V2-1 P1033087V2-1 CONTACTOR SDE MA-18 220-240V (G1033)
37 P1033037 FLAT WASHER 6MM 87V2-1 P1033Z087V2-1 CONTACTOR SDE MA-30 220-240V (G1033Z)
38 P1033038 HEX BOLT M6-1 X 12 87V2-2 P1033087V2-2 OL RELAY SDE RA-30 18-26A (G1033)
38V2 P1033038V2 FLANGE BOLT M6-1 X 12 V2.05.18 87V2-2 P1033Z087V2-2 OL RELAY SDE RA-30 22-34A (G1033Z)
39 P1033039 CHIPBREAKER ADJUSTMENT ROD 87V2-3 P1033087V2-3 MAGNETIC SWITCH COVER (FRONT) (G1033)
40 P1033040 CHIPBREAKER ADJUSTMENT BRACKET 87V2-3 P1033Z087V2-3 MAGNETIC SWITCH COVER (FRONT) (G1033Z)
41 P1033041 PRESSURE BAR 87V2-4 P1033087V2-4 MAGNETIC SWITCH COVER (REAR) (G1033)
42 P1033042 LOCK WASHER 8MM 87V2-4 P1033Z087V2-4 MAGNETIC SWITCH COVER (REAR) (G1033Z)
43 P1033043 SHAFT 93 P1033093 MOTOR CORD 12G 3W 57" (G1033)
44 P1033044 SET SCREW M6-1 X 20 93 P1033Z093 MOTOR CORD 10G 3W 57" (G1033Z)
45 P1033045 SET SCREW M6-1 X 16 95 P1033095 CAP SCREW M6-1 X 12
46 P1033046 FLAT SPRING 84 X 46 X 0.6MM 96 P1033096 SET SCREW M8-1.25 X 12
47 P1033047 CHIP DEFLECTOR 97V2 P1033097V2 FENDER WASHER 6 X 22 X 3MM V2.05.18
48 P1033048 ANTI-KICKBACK FINGER 98 P1033098 SLEEVE 13.5 ID X 30 L
49 P1033049 SPACER 108 P1033108 PHLP HD SCR M6-1 X 12
50 P1033050 ANTI-KICKBACK SHAFT 110 P1033110 FLAT HD CAP SCR M5-.8 X 10
51 P1033051 E-CLIP 15MM 111 P1033111 SPROCKET 31T
52 P1033052 DEPTH LIMITER 112 P1033112 HEX BOLT M8-1.25 X 20
53 P1033053 FLAT HD SCR M5-.8 X 12 113 P1033113 PHLP HD SCR M4-.7 X 8
54 P1033054 UPPER COVER 114 P1033114 PULLEY GUARD PLATE
55 P1033055 UPPER COVER GASKET 115 P1033115 CHIP BREAKER GASKET
