Model G1033/X/Z (Mfd. Since 02/19)
-57-
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
G1033/G1033Z Main Parts List (Cont.)
REF PART # DESCRIPTION REF PART # DESCRIPTION
215 P1033215 POINTER 534 P1033534 KNOB 3/8-16, D1-1/4, BALL
216 P1033216 CAP SCREW M5-.8 X 10 535 P1033535 LOCATING PIN 8 X 7.55 X 7.95
217 P1033217 LOCK WASHER 5MM 536 P1033536 GEARBOX COVER GASKET
417V2 P1033417V2 POWER CORD 12G 3W 138" 6-20P V2.05.18 537V2 P1033537V2 GEARBOX COVER V2.05.18
414V2 P1033Z414V2 MOTOR 5HP 230V 1-PH V2.05.18 (G1033Z) 538 P1033538 CAP SCREW M6-1 X 25
501V2 P1033501V2 GEARBOX V2.05.18 539V2 P1033539V2 OIL PLUG 1/4 NPT X 3/4" V2.05.18
502 P1033502 OIL SEAL 28 X 40 X 8 540 P1033540 CAP SCREW M8-1.25 X 50
503 P1033503 BALL BEARING 6204ZZ 601V2 P1033601V2 SPROCKET 31T V2.05.18
504 P1033504 GEAR 16T 602 P1033602 FENDER WASHER 6 X 20 X 3MM
505V2 P1033505V2 CAP SCREW M6-1 X 25 V2.05.18 603 P1033603 HEX BOLT M6-1 X 16
506 P1033506 FLAT WASHER 6 X 20 X 3MM 604V2 P1033604V2 SPROCKET 31T V2.05.18
507 P1033507 CAP SCREW M6-1 X 12 605 P1033605 ROLL PIN 6 X 20
508 P1033508 BALL BEARING 6201ZZ 606 P1033606 CHAIN 06B-1 X 67 33 LINKS
509 P1033509 GEAR 47T 607 P1033607 CAP SCREW M6-1 X 10
510 P1033510 GEARED SHAFT 18T 608 P1033608 CHAIN TENSIONER
511 P1033511 KEY 5 X 5 X 12 609 P1033609 SHOULDER BOLT M8-1.25 X 14, 12 X 4
512 P1033512 GEAR 71T 610 P1033610 SPRING BRACKET
513 P1033513 KEY 5 X 5 X 10 611 P1033611 EXTENSION SPRING 1 X 8.5 X 33
514V2 P1033514V2 GEARED SHAFT 28T/18T V2.02.19 612 P1033612 SPACER 8.2 X 22 X 3MM
517V2 P1033517V2 COMBO GEAR 86T/96T V2.02.19 613 P1033613 OUTER CHAIN TENSIONER
520 P1033520 KEY 6 X 6 X 40 614 P1033614 SPROCKET 12T W/KEY
521 P1033521 STEEL BALL 6MM 615 P1033615 CHAIN 06B-1 25 LINKS
522 P1033522 COMPRESSION SPRING 0.6 X 5.9 X 16 616 P1033616 CAP SCREW M6-1 X 35
523 P1033523 GEAR SHAFT 617 P1033617 FLAT WASHER 6MM
524 P1033524 OIL SEAL 25 X 47 X 6 619 P1033619 CHAIN TENSIONER IDLER WHEEL
529 P1033529 SHIFTING FORK 620 P1033620 CHAIN TENSIONER IDLER SHAFT
530 P1033530 SHIFTING SHAFT 621 P1033621 OUTER CHAIN TENSIONER IDLER WHEEL
532V2 P1033532V2 FLANGE BOLT M6-1 X 12 V2.05.18 622 P1033622 OUTER CHAIN TENSIONER IDLER SHAFT
533 P1033533 O-RING 12 X 1.5 S12.5
To Next Page
