Grizzly G1033X User Manual

-64-
Model G1033/X/Z (Mfd. Since 02/19)
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
G1033X Main Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P1033X001 KNOB 5/16-18, D1-3/4, ROUND 52A P1033X052A SPIRAL CUTTERHEAD ASSY V2.07.07
2 P1033X002 V-BELT COVER 52A-1 P1033X052A-1 INSERTS 15 X 15 X 2.5-10 PK
3V2 P1033X003V2 V-BELT M57 3L 570 V2.05.13 52A-2 P1033X052A-2 FLAT HEAD TORX 10-32 X 1/2
4 P1033X004 STANDOFF-HEX MM 5/16-18 X 1/2, 2-5/16 52A-3 P1033X052A-3 SPIRAL CUTTERHEAD BODY V2.07.07
5 P1033X005 HEX BOLT M8-1.25 X 20 53 P1033X053 COMPRESSION SPRING 19.7 X 12
6 P1033X006 FENDER WASHER 8MM 54 P1033X054 BUSHING BLOCK
7 P1033X007 FLANGE SCREW M6-1 X 12 55 P1033X055 BUSHING BLOCK PLATE
8 P1033X008 PULLEY GUARD 56 P1033X056 LOCK WASHER 8MM
9 P1033X009 HEX NUT 5/16-18 57 P1033X057 PRESSURE BAR
10 P1033X010 CUTTERHEAD PULLEY 58 P1033X058 OUTFEED ROLLER
11 P1033X011 DUST HOOD 5" 60V2 P1033X060V2 SPROCKET 31T V2.05.18
12 P1033X012 HEX BOLT M6-1 X 12 61 P1033X061 FLAT WASHER 6MM
13 P1033X013 FLAT WASHER 6MM 62 P1033X062 HEX BOLT M6-1 X 16
14 P1033X014 CAP SCREW M6-1 X 12 63 P1033X063 BRACKET
15 P1033X015 UPPER COVER 64 P1033X064 SHAFT 15.875 X 710
16 P1033X016 FLAT WASHER 6MM 65 P1033X065 CHIP BREAKER
17 P1033X017 CAP SCREW M6-1 X 16 66V2 P1033X066V2 SPROCKET 31T V2.05.18
18 P1033X018 HANDWHEEL ASSEMBLY 67 P1033X067 EXT RETAINING RING 12MM
18-1 P1033X018-1 HANDWHEEL TYPE-2 200D X 12B-K X 3/8-16 68 P1033X068 E-CLIP 15MM
18-2 P1033X018-2 REVOLVING HANDLE 1 X 3-3/8, 3/8-16 X 1/2 69 P1033X069 SPACER
20 P1033X020 GASKET 70 P1033X070 ANTI-KICKBACK FINGER
21 P1033X021 CHIP DEFLECTOR 71 P1033X071 LOCK ROD
22 P1033X022 SPRING PLATE 72 P1033X072 SHAFT 19.95 X 680
23 P1033X023 SET SCREW M6-1 X 16 73 P1033X073 HEX NUT M12-1.75
24 P1033X024 SPRING PLATE 74 P1033X074 INFEED ROLLER
25 P1033X025 OILER SCREW M22-1.5 75 P1033X075 CHAIN
26 P1033X026 FLAT WASHER 8MM 76 P1033X076 CAP SCREW M8-1.25 X 50
27 P1033X027 CHAIN TENSIONER 77 P1033X077 BALL BEARING 6204ZZ
28 P1033X028 SHAFT M22-.5 X 20 78 P1033X078 GEAR 16T
29 P1033X029 IDLER WHEEL 79 P1033X079 CAP SCREW M6-1 X 25
30 P1033X030 IDLER SHAFT 19.05 X 21MM 80 P1033X080 BALL BEARING 6201ZZ
31V2 P1033X031V2 GEARBOX COVER PLATE-B V2.11.18 81 P1033X081 GEAR 47T
32 P1033X032 ROLL PIN 6 X 20 82 P1033X082 GEARED SHAFT 18T
33V2 P1033X033V2 DRIVE CHAIN COVER V2.11.18 83 P1033X083 KEY 5 X 5 X 12
34V2 P1033X034V2 CAP SCREW M8-1.25 X 10 V2.11.18 84V2 P1033X084V2 GEARBOX COVER V2.11.18
35 P1033X035 EXTENSION SPRING 8.5 X 14 85 P1033X085 LOCATING PIN 8 X 7.55 X 7.95
36 P1033X036 SPRING BRACKET 86V2 P1033X086V2 GEAR 28T/18T 2-SPEED V2.02.19
38V2 P1033X038V2 GEARBOX COVER PLATE-A V2.11.18 87 P1033X087 KEY 6 X 6 X 40
40 P1033X040 SET SCREW M10-1.5 X 12 88 P1033X088 KEY 5 X 5 X 10
41 P1033X041 SET SCREW M8-1.25 X 12 89 P1033X089 GEAR 71T
42 P1033X042 HEAD CASTING 90 P1033X090 KNOB 3/8-16, D1-5/16, BALL
43 P1033X043 SHAFT 15.875 X 60 91 P1033X091 SPROCKET & CHAIN ASSY
44 P1033X044 HEX NUT M6-1 91-1 P1033X091-1 CHAIN
45 P1033X045 SET SCREW M6-1 X 20 91-2 P1033X091-2 SPROCKET
46 P1033X046 FLAT HD SCR M5-.8 X 8 91-3 P1033X091-3 OUTER CHAIN TENSIONER
47 P1033X047 DEPTH LIMITER 91-4 P1033X091-4 SHAFT 19.05 X 21
48 P1033X048 HEX BOLT M8-1.25 X 20 91-5 P1033X091-5 BRACKET
49 P1033X049 SCALE ASSEMBLY 91-6 P1033X091-6 CAP SCREW M6-1 x 35
49-1 P1033X049-1 PHLP HD SCR M6-1 X 12 91-7 P1033X091-7 FLAT WASHER 6MM
49-2 P1033X049-2 POINTER 93V2 P1033X093V2 OIL PLUG 1/4 NPT X 3/4" V2.11.18
49-3 P1033X049-3 SCALE 94 P1033X094 OIL SEAL 28 X 40 X 8
49-4 P1033X049-4 CAP SCREW M5-.8 X 10 95V2 P1033X095V2 GEARBOX V2.11.18
50 P1033X050 BALL BEARING 6206ZZ 95AV2 P1033X095AV2 GEARBOX ASSY V2.11.18
51 P1033X051 KEY 8 X 8 X 35 96 P1033X096 GASKET
