G1033X Main Parts List (Cont.)
REF PART # DESCRIPTION REF PART # DESCRIPTION
97V2 P1033X097V2 COMBO GEAR 86T/96T V2.02.19 172 P1033X172 RETURN ROLLER
98 P1033X098 FLANGE SCREW M6-1 X 16 173 P1033X173 BEARING SHAFT
99 P1033X099 SHAFT 20 X 106 174 P1033X174 WORM GEAR HOUSING
100 P1033X100 COMPRESSION SPRING 5.9 X 9 175 P1033X175 CAP SCREW M6-1 X 50
101 P1033X101 STEEL BALL 6MM 176 P1033X176 WORM SHAFT
102 P1033X102 OIL SEAL 25 X 47 X 6 177 P1033X177 INT RETAINING RING 32MM
103 P1033X103 BALL BEARING 6204ZZ 178 P1033X178 COLLAR
104 P1033X104 SHIFTER 179 P1033X179 FLAT WASHER 6MM
105 P1033X105 SHIFTING SHAFT 180 P1033X180 CAP SCREW M6-1 X 10
106 P1033X106 O-RING 12 X 2.4 200 P1033X200 CAP SCREW M6-1 X 10
116 P1033X116 SET SCREW M6-1 X 12 201 P1033X201 BALL BEARING 6202ZZ
117 P1033X117 BALL BEARING 6201ZZ 233 P1033X233 T-HANDLE T-25 TORX DRIVER
133 P1033X133 FLAT WASHER 12MM 245 P1033X245 PHLP HD SCR M4-.7 X 8
159 P1033X159 KEY 4 X 4 X 10 246 P1033X246 SPROCKET 31T
171 P1033X171 RETURN ROLLER BRACKET
