2.5 Electrical Connection Warnings
2.6 Operation Warnings
DANGER
 The components in the inverter are live. Touching live components can result
in serious injury or death.
 Do not open the inverter except the wire box by qualified persons.
 Electrical installation, repairs and conversions may only be carried out by
electrically qualified persons.
 Do not touch damaged inverters.
 Danger to life due to high voltages in the inverter
 There is residual voltage in the inverter. The inverter takes 20 minutes to
discharge.
 Persons with limited physical or mental abilities may only work with the
Growatt inverter following proper instruction and under constant supervision.
Children are forbidden to play with the Growatt inverter. Must keep the
Growatt inverter away from children.
WARNING
 Make all electrical connections (e.g. conductor termination, fuses, PE
connection, etc.) in accordance with prevailing regulations. When working
with the inverter powered on, adhere to all prevailing safety regulations to
minimize risk of accidents.
 Systems with inverters typically require additional control (e.g., switches,
disconnects) or protective devices (e.g., fusing circuit breakers) depending
upon the prevailing safety rules.
WARNING
 Ensure all connectors are sealed and secure during operation.
 Although designed to meet all safety requirements, some parts and
surfaces of Inverter are still hot during operation. To reduce the risk of
injury, do not touch the heat sink at the back of the PV-Inverter or nearby
surfaces while Inverter is operating.
 Incorrect sizing of the PV plant may result in voltages being present
which could destroy the inverter. The inverter display will read the error
message “PV voltage High!”
 Turn the rotary switch of the DC Disconnect to the Off position
immediately.
 Contact installer.
CAUTION
 All operations regarding transport, installation and start-up, including
maintenance must be operated by qualified, trained personnel and in
compliance with all prevailing codes and regulations.
 Anytime the inverter has been disconnected from the power network, use
extreme caution as some components can retain charge sufficient to

Growatt MIN 5000 TL-X Specifications

General

Max. DC Voltage	550 V
Nominal AC Output Power	5000 W
Max. Efficiency	98.4%
MPPT Efficiency	99.9 %
Weight	10.8 kg
Protection Rating	IP65
Number of MPP Trackers	2
Max. Input Current per MPPT	11 A
Max. AC Power	5000 W
Nominal AC Voltage	230 V
AC Voltage Range	180 V - 280 V
Nominal Grid Frequency	50 Hz / 60 Hz
Total Harmonic Distortion	<3%
DC Switch	Yes
Protection Class	Class I
Topology	Transformerless
Cooling	Natural convection
Max. PV Input Power	6000 W
Max. PV Input Voltage	550 V
Max. Input Current	22 A
AC Output Voltage	230 V
AC Output Frequency	50 Hz / 60 Hz
Peak Efficiency	98.4%
Operating Temperature Range	-25°C to 60°C
Power Factor Adjustment Range	0.8 leading - 0.8 lagging
Dimensions (W x H x D)	375 x 350 x 160 mm
