Page #43 background image
43
10.3 Inverter warning
Warning code
Meanings
Suggestion
Warning202
DC SPD function abnormal
1.After shutdown,Check the DC SPD.
2.If error message still exists,contact
manufacturer.
Warning 203
PV1 or PV2 Circuit short
Check the PV panel polarity.
Restart the inverter. If the warning still
exist, please contact Growatt customer
service to replace the POWER board.
Warning204
Dryconnect function abnormal
1.After shutdown,Check the dry
Dryconnect wiring.
2.If the error message still exists, contact
manufacturer.
Warning 205
PV1 or PV2 boost broken
Restart the inverter. If the warning still
exist, please contact Growatt customer
service to replace the power board.
Warning207
USB over-current
1: Unplug the U disk or monitor.
2: Re-access U disk or monitor after
shutdown.
3.If the error message still exists, contact
manufacturer.
Warning 401
Inverter communicates with
Meter abnormal
1: Check if the meter is on
2: Check the inverter and the meter
connection is normal
Warning404
EEPROM abnormal
Restart the inverter. If the warning still
exist, please contact Growatt customer
service to replace the M3 board.
Warning405
Firmware version is not
consistent
Uptate the right version firmware
10.4 Inverter fault
Error code
Meanings
Suggestion
Error: 402
Output High DCI
Restart inverter, if problem still exist,
Contact Growatt.
Error: 404
Bus sample fault
Restart inverter, if problem still exist,
Contact Growatt.
Error: 405
Relay fault
Restart inverter, if problem still exist,
Contact Growatt.
Error: 408
Over Temperature
If the ambient temperature of inverter is
