Growatt MIN 5000 TL-X User Manual

16
package.
 The storage temperature should be always between -25℃and +60℃. And the
storage relative humidity can achieve to 100%.
 If there are a batch of inverters need to be stored, the maximum layers for original
carton is four.
 After long term storage, local installer or service department of GROWATT
should perform a comprehensive test before installation.
3.5 The advantage of the unit
 Maximum efficiency of 98.4%
 Wide input voltage range from 80--550Vdc
 Reactive power regulate
 Integrated DC switch
 Multi MPP controller
 DSP controller
 Touch control
 Multi active power control mode
 Easy installation
4 Unpacking and inspection
The inverter is thoroughly tested and inspected strictly before delivery. Our inverters
leave our factory in proper electrical and mechanical condition. Special packaging
ensures safe and careful transportation. However, transport damage may still occur.
The shipping company is responsible in such cases. Thoroughly inspect the inverter
upon delivery. Immediately notify the responsible shipping company if you discover
any damage to the packaging which indicates that the inverter may have been
damaged or if you discover any visible damage to the inverter. We will be glad to
assist you, if required. When transporting the inverter, the original or equivalent
packaging should be used, and the maximum layers for original carton is four, as this
ensures safe transport.
After opening the package, please check the contents of the box. It should contain the
following, Please check all of the accessories carefully in the carton. If anything
missing, contact your dealer at once.

Growatt MIN 5000 TL-X Specifications

General

Max. DC Voltage	550 V
Nominal AC Output Power	5000 W
Max. Efficiency	98.4%
MPPT Efficiency	99.9 %
Weight	10.8 kg
Protection Rating	IP65
Number of MPP Trackers	2
Max. Input Current per MPPT	11 A
Max. AC Power	5000 W
Nominal AC Voltage	230 V
AC Voltage Range	180 V - 280 V
Nominal Grid Frequency	50 Hz / 60 Hz
Total Harmonic Distortion	<3%
DC Switch	Yes
Protection Class	Class I
Topology	Transformerless
Cooling	Natural convection
Max. PV Input Power	6000 W
Max. PV Input Voltage	550 V
Max. Input Current	22 A
AC Output Voltage	230 V
AC Output Frequency	50 Hz / 60 Hz
Peak Efficiency	98.4%
Operating Temperature Range	-25°C to 60°C
Power Factor Adjustment Range	0.8 leading - 0.8 lagging
Dimensions (W x H x D)	375 x 350 x 160 mm
