Growatt MIN 5000 TL-X User Manual

33
6.8 Inverter demand response modes (DRMS)
This series inverter has the function of demand response modes, We use 8Pin socket
as inverter DRMS connection.
Information
DRMS application description
 Only applicable to AS/NZS4777.2:2015.
 DRM0, DRM5, DRM6, DRM7, DRM8 are available.
CAUTION
Damage to the inverter due to moisture and dust penetration
 Make sure the cable gland has been tightened firmly.
 If the cable gland are not mounted properly, the inverter can
be destroyed due to moisture and dust penetration. All the
warranty claim will be invalid.
6.8.1 8Pin socket pin assignment
Pin
Assignment for inverters capable
of both charging and discharging
1
DRM 5
2
DRM 6
3
DRM 7
4
DRM 8
5
RefGen
6
Com/DRM0
7
NC
8
NC
6.8.2 Method of asserting demand response modes
Mode
Socket Asserted
by shorting pins
Requirement
DRM 0
5
6
Operate the disconnection device
DRM 5
1
5
Do not generate power
DRM 6
2
5
Do not generate at more than 50% of rated power
DRM 7
3
5
Do not generate at more than 75% of rated power
AND Sink reactive power if capabie
DRM 8
4
5
Increase power generation (subject to constraints from
other active DRMs)
7 Commissioning

Growatt MIN 5000 TL-X Specifications

General

Max. DC Voltage	550 V
Nominal AC Output Power	5000 W
Max. Efficiency	98.4%
MPPT Efficiency	99.9 %
Weight	10.8 kg
Protection Rating	IP65
Number of MPP Trackers	2
Max. Input Current per MPPT	11 A
Max. AC Power	5000 W
Nominal AC Voltage	230 V
AC Voltage Range	180 V - 280 V
Nominal Grid Frequency	50 Hz / 60 Hz
Total Harmonic Distortion	<3%
DC Switch	Yes
Protection Class	Class I
Topology	Transformerless
Cooling	Natural convection
Max. PV Input Power	6000 W
Max. PV Input Voltage	550 V
Max. Input Current	22 A
AC Output Voltage	230 V
AC Output Frequency	50 Hz / 60 Hz
Peak Efficiency	98.4%
Operating Temperature Range	-25°C to 60°C
Power Factor Adjustment Range	0.8 leading - 0.8 lagging
Dimensions (W x H x D)	375 x 350 x 160 mm
