Growatt MIN 5000 TL-X User Manual

49
unit
General data
Dimensions (W / H / D) in mm
375*350*160
Weight
10.8 kg
Operating temperature range
–25 °C ... +60 °C
Noise emission (typical)
≤ 25 dB(A)
Altitude
4000m
Internal consumption at night
<1W
Topology
transformerless
Cooling
Natural convection
Protection degree
IP65
Relative humidity
0~100%
DC connection
VP-D4/MC4(Optional)
AC connection
AC connector
Interfaces
Display
OLED+LED
RS485/USB
Integrated
WIFI/GPRS/4G/LAN/ RF
Optional
Warranty:5/10 years
Yes/ Optional
13.2 DC &AC connector info
DC connector
VP-D4/ MC4(opt)
AC connector
M-S30_SD03_S10 001U-A
VPAC06EP-3S(SC)5
VPAC06EW-3P(SC)
13.3 Torque
Enclosure lid screws
12kg.cm
AC terminal
6kg.cm
Signal terminal
4kg.cm
Safety screw
12kg.cm
Additional ground screws
12kg.cm
13.4 Accessories
In the following table you will find the optional accessories for your product. If
required, you can order these from GROWATT NEW ENERGY TECHNOLOGY

Growatt MIN 5000 TL-X Specifications

General

Max. DC Voltage	550 V
Nominal AC Output Power	5000 W
Max. Efficiency	98.4%
MPPT Efficiency	99.9 %
Weight	10.8 kg
Protection Rating	IP65
Number of MPP Trackers	2
Max. Input Current per MPPT	11 A
Max. AC Power	5000 W
Nominal AC Voltage	230 V
AC Voltage Range	180 V - 280 V
Nominal Grid Frequency	50 Hz / 60 Hz
Total Harmonic Distortion	<3%
DC Switch	Yes
Protection Class	Class I
Topology	Transformerless
Cooling	Natural convection
Max. PV Input Power	6000 W
Max. PV Input Voltage	550 V
Max. Input Current	22 A
AC Output Voltage	230 V
AC Output Frequency	50 Hz / 60 Hz
Peak Efficiency	98.4%
Operating Temperature Range	-25°C to 60°C
Power Factor Adjustment Range	0.8 leading - 0.8 lagging
Dimensions (W x H x D)	375 x 350 x 160 mm
