Growatt MIN 5000 TL-X User Manual

48
MPP voltage range
80-550
80-550
80-550
MPP voltage range at Full
Power
185V-500V
200V-500V
235V-500V
No. of MPP trackers
2
No. of PV strings per MPP
trackers
1
Max. input current per MPP
trackers
12.5A
Max. short-circuit current per
MPP trackers
16A
DC overvoltage category
Category II
Output data(AC)
AC nominal power
4.6kW
5kW
6kW
Max. AC apparent power
4.6kVA
5kVA
6kVA
Nominal AC voltage/range*
230/
160~300V
230/
160~300V
230/
160~300V
AC grid frequency/range
50-60Hz/44-55Hz;54-65Hz
Max. output current
20.9
22.7A
27.2A
Inrush current
<10A
Max output fault current
53A
Max output overload protection
25A
32A
32A
Backfeed current
0A
Power factor(@nominal
power)
>0.99
Adjustable power factor
0.8leading… 0.8lagging
THDi
<3%
AC grid connection type
Single phase
AC overvoltage category
Category III
Efficiency
Max. efficiency
98.4%
98.4%
98.4%
Euro-eta
97.5%
97.5%
97.5%
Protection devices
DC reverse-polarity protection
Integrated
DC switch
Integrated
DC Surge protection
Type II
Insulation resistance
monitoring
Integrated
AC surge protection
Type III
AC short-circuit protection
Integrated
Ground fault monitoring
Integrated
Grid monitoring
Integrated
Anti-islanding protection
Integrated
Residual-current monitoring
Integrated

Growatt MIN 5000 TL-X Specifications

General

Max. DC Voltage	550 V
Nominal AC Output Power	5000 W
Max. Efficiency	98.4%
MPPT Efficiency	99.9 %
Weight	10.8 kg
Protection Rating	IP65
Number of MPP Trackers	2
Max. Input Current per MPPT	11 A
Max. AC Power	5000 W
Nominal AC Voltage	230 V
AC Voltage Range	180 V - 280 V
Nominal Grid Frequency	50 Hz / 60 Hz
Total Harmonic Distortion	<3%
DC Switch	Yes
Protection Class	Class I
Topology	Transformerless
Cooling	Natural convection
Max. PV Input Power	6000 W
Max. PV Input Voltage	550 V
Max. Input Current	22 A
AC Output Voltage	230 V
AC Output Frequency	50 Hz / 60 Hz
Peak Efficiency	98.4%
Operating Temperature Range	-25°C to 60°C
Power Factor Adjustment Range	0.8 leading - 0.8 lagging
Dimensions (W x H x D)	375 x 350 x 160 mm
