Growatt MIN 5000 TL-X User Manual

47
Max. efficiency
98.2%
98.2%
98.2%
98.4%
Euro-eta
97.1%
97.1%
97.2%
97.2%
Protection devices
DC reverse-polarity protection
Integrated
DC switch
Integrated
DC Surge protection
Type II
Insulation resistance
monitoring
Integrated
AC surge protection
Type III
AC short-circuit protection
Integrated
Ground fault monitoring
Integrated
Grid monitoring
Integrated
Anti-islanding protection
Integrated
Residual-current monitoring
unit
Integrated
General data
Dimensions (W / H / D) in mm
375*350*160
Weight
10.8 kg
Operating temperature range
–25 °C ... +60 °C
Noise emission (typical)
≤ 25 dB(A)
Altitude
4000m
Internal consumption at night
<1W
Topology
transformerless
Cooling
Natural convection
Protection degree
IP65
Relative humidity
0~100%
DC connection
VP-D4/MC4(Optional)
AC connection
AC connector
Interfaces
Display
OLED+LED
RS485/USB
Integrated
WIFI/GPRS/4G/LAN/ RF
Optional
Warranty:5/10 years
Yes/ Optional
Model
Specifications
4600TL-X
5000TL-X
6000TL-X
Input data(DC)
Max. recommended PV
power(for module STC)
6440W
7000W
8100W
Max. DC voltage
550V
Start voltage
100V
Nominal voltage
360V

Growatt MIN 5000 TL-X Specifications

General

Max. DC Voltage	550 V
Nominal AC Output Power	5000 W
Max. Efficiency	98.4%
MPPT Efficiency	99.9 %
Weight	10.8 kg
Protection Rating	IP65
Number of MPP Trackers	2
Max. Input Current per MPPT	11 A
Max. AC Power	5000 W
Nominal AC Voltage	230 V
AC Voltage Range	180 V - 280 V
Nominal Grid Frequency	50 Hz / 60 Hz
Total Harmonic Distortion	<3%
DC Switch	Yes
Protection Class	Class I
Topology	Transformerless
Cooling	Natural convection
Max. PV Input Power	6000 W
Max. PV Input Voltage	550 V
Max. Input Current	22 A
AC Output Voltage	230 V
AC Output Frequency	50 Hz / 60 Hz
Peak Efficiency	98.4%
Operating Temperature Range	-25°C to 60°C
Power Factor Adjustment Range	0.8 leading - 0.8 lagging
Dimensions (W x H x D)	375 x 350 x 160 mm
