Growatt MIN 5000 TL-X - Page 27

27
5:To remove the AC output terminal, press the bayonet out of the slot with a small screwdriver and
pull it out,or unscrew the threaded sleeve,then pull it out.
Wire suggestion length：
Conductor cross
section
Max. cable length
MIN 2500 TL-X
MIN 3000 TL-X
MIN 3600 TL-X
4 mm² 12AWG
48m
40m
33m
