4.2.1.4 Setting Initial and Final Address
1. In “parameter” field, under “Addren_star”, default initial address is 1, and under
“Addren_end”, default final address is 32. The initial address could be changed
within the range up to final address. All the inverters under monitoring should be in
the range between initial address and final address, otherwise, the inverters out of
range could not be monitored normally.
Addren_start:
Addren_end:
1
32
2. Click on “save”, configuration has been carried out successfully.
4.2.1.5 Setting ZigBee
1. Setting ID for ZigBee, in “parameter” field, select “ZigBee_ID”, enter ZigBee ID
within the range between 1000 and 9999.
2. Setting channel for ZigBee, in “parameter” field, select “ZigBee_channel”, enter
the ZigBee channel within the range between 11 and 25.
3. If the parameters about ZigBee have been modified in the web browser accessing
to the Shine WebBox, the configuration of ZigBee module connecting to the inverter
also needs to be modified. As to detailed information, please refer to ZigBee module
user manual.
4.2.1.6 Setting Environmental Monitor and Smart-meter
The Shine WebBox currently supports the data exchange with environmental monitor
and smart-meter; you can activate this function by using the web browser in the local
network.
19
