Growatt SPH3600 Installation Manual

Chart 5.3
J. Do not install the machine near television antenna or any other antennas and antenna cables
K. Don’t install the machine in the living area
L. Be sure that the machine is out of the children’s reach
M. Taking the battery fixing space into account, about the dimensions please reference user manual
N. The inflammable and explosive dangerous goods must not be placed around battery in case of cause
serious danger.
5.2 Installation requires tools and RJ 45 terminal sequence of the LAN line。
When installing, we need to use tools as follow, prepare the follow tools before installing：
Chart 5.4
No. Description
1 Press the RJ45 terminal
2 Press battery terminal connector
3 Disconnect PV terminal
4 Unscrew nut
5 Unscrew screw
6 Knock explosion bolt
7 Drill holes on the wall

Growatt SPH3600 Specifications

General

Model	SPH3600
Type	Hybrid Inverter
Rated Power	3600 W
Max PV Input Voltage	550 V
Number of MPPTs	2
Max Input Current per MPPT	11 A
Nominal DC Voltage	360 V
Nominal AC Power	3600 W
Max AC Current	16 A
Nominal AC Voltage	230 V
AC Voltage Range	180-280V
Nominal Grid Frequency	50/60 Hz
THDi	<3%
Max Efficiency	97.5%
DC Switch	Yes
Protection Degree	IP65
Battery Voltage Range	42 V - 59 V
Communication Interfaces	RS485, WiFi
Max AC Power	3600W
Euro Efficiency	97.0%
Operating Temperature Range	-25°C to +60°C
Cooling	Natural Convection
