Page #14 background image
PV voltage range 120-550 d.c.V
PV Isc 16.9 d.c.A*2
Max.input current 13.5d.c.A*2
AC input / output data
Rated input / output power
3000/6000 W
Rated output apparent power
6000VA
Nominal voltage 230 a.c.V
Rated input / output current
13.5/27 a.c.A
Nominal Frequency 50 Hz
Power factor range 0.8leading~0.8lagging
EPS output data
Rated output apparent power
3000VA
Nominal voltage 230 a.c.V
Rated output current 13.5 a.c.A
Nominal Frequency 50 Hz
Power factor range 0.8leading~0.8lagging
Battery data
Battery voltage range 42~59 d.c.V
Rated charging and
discharging current
66 d.c.A
Type of Battery Lithium/Lead-acid
other
Safety level Class I
Overvoltage category PV:II AC:III Others:I
Ingress protection IP65
Operation Ambient
Temperature
-25℃~+60℃

Other manuals for Growatt SPH5000

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Growatt SPH5000 and is the answer not in the manual?

Growatt SPH5000 Specifications

General IconGeneral
ModelSPH5000
TypeHybrid Inverter
Rated Power5000 W
Max. DC Voltage550 V
Max. Output Current22 A
Weight25 kg
Max. DC Power6000 W
Start Voltage150 V
Nominal DC Voltage360 V
Number of MPP Trackers2
AC Nominal Power5000 W
Max. AC Apparent Power5000 VA
AC Nominal Voltage230 V
AC Voltage Range180-280V
Nominal Grid Frequency50/60Hz
Total Harmonic Distortion (THDi)<3%
Power Factor Adjustment Range0.8 leading to 0.8 lagging
DC Injection Current<0.5% In
Switching Time<10 ms
Max. Charge/Discharge Power5000 W
Max. Charge/Discharge Current100 A
Protection degreeIP65
Max. PV Input Voltage550 V
Cooling MethodNatural Convection
Communication with BMSCAN
Operating Temperature Range-25°C to 60°C
MPPT Voltage Range120 V - 550 V
