Growatt SPH5000 Installation Manual

Dimensions (W /
H / D) in mm
461*565*188
Weight 27KG
Noise emission
(typical)
≤ 25 dB(A)
Altitude
2000m
Self-Consumptio
n
< 10 W
Cooling concept Natural
Relative humidity 100%
Features
DC connection MC4/H4(opt)
AC connection connector
BAT connection
OT Terminal
Display LCD
Interfaces:
RS485/ USB
/CAN/Wi-Fi/GPR
S
yes /yes /yes/yes
Warranty: 5
years / 10 years
yes /opt
Certificates and
approvals
CE, IEC62109, G98/G99, VDE0126-1-1, AS4777, CEI 0-21, VDE-AR-N4105, UTE C 15-712，
EN50549, IEC 61727, IEC 62116, IEC 62040 ,,C10/11,NRS 097-2-1
Note:
1.
*1
Continuous charging current: if there is PV and the PV power is large enough, the maximum
continuous charging power can reach 4000W; If there is no PV, only AC is connected, the maximum
continuous charging power is 3000W.
12.2 DC input terminal parameter
MC4 specification:
2.5mm
2
/14AWG 4mm
2
/12 AWG 6mm
2
/10 AWG 10mm
2
/8AWG
Rated current
(90℃environment)
32A 40A 44A 65A
Nominal system voltage
600V DC(UL)
600V DC(TUV)
Contact resistance
0.25mΩ（model）
Protection grade IP68
Socket contact materials Copper, tin
Insulation materials Thermoplastics UL94 V-0
Ambient temperature range -40℃ to +90℃
Wire stripping length 7.0mm(9/32)

Growatt SPH5000 Specifications

General

Model	SPH5000
Type	Hybrid Inverter
Rated Power	5000 W
Max. DC Voltage	550 V
Max. Output Current	22 A
Weight	25 kg
Max. DC Power	6000 W
Start Voltage	150 V
Nominal DC Voltage	360 V
Number of MPP Trackers	2
AC Nominal Power	5000 W
Max. AC Apparent Power	5000 VA
AC Nominal Voltage	230 V
AC Voltage Range	180-280V
Nominal Grid Frequency	50/60Hz
Total Harmonic Distortion (THDi)	<3%
Power Factor Adjustment Range	0.8 leading to 0.8 lagging
DC Injection Current	<0.5% In
Switching Time	<10 ms
Max. Charge/Discharge Power	5000 W
Max. Charge/Discharge Current	100 A
Protection degree	IP65
Max. PV Input Voltage	550 V
Cooling Method	Natural Convection
Communication with BMS	CAN
Operating Temperature Range	-25°C to 60°C
MPPT Voltage Range	120 V - 550 V
