Page #61 background imageLoading...
Page #61 background image
recommended
PV power(for
module STC)
Max. DC voltage
550V 550V 550V 550V 550V 550V
Start voltage 120V 120V 120V 120V 120V 120V
Nominal voltage
370V 370V 370V 370V 370V 370V
MPP work
voltage range
120V-550V
120V-550V
120V-550V
120V-550V
120V-550V
120V-550V
Full load dc
voltage range
275V-440V 275V-440V 275V-440V 340V-440V 340V-440V 340V-440V
Number of
independent
MPP trackers
2
No. of
PV strings
per MPP trackers
1
Max. input
current per MPP
trackers
13.5A
Max. short-circuit
current per MPP
trackers
16.9A
Backfeed current
to the array
0A
AC output/input data
Gowatt
SPH&SPH TL
BL-UP Rated
input / output
power
3000/3000
W&3000/300
0W
3000/3680
W&3680/368
0 W
3000/4000W
& 4000
/4000
W
3000/4600
W&4600/460
0
3000/5000
W&5000/500
0
3000/6000
W&6000/6000
W
Rated output
apparent power
3000VA 3680VA 4000VA 4600VA 5000VA 6000VA
Nominal AC
voltage/range
230V ;
180Vac-260
Vac
230V ;
180Vac-260
Vac
230V ;
180Vac-260
Vac
230V ;
180Vac-260
Vac
230V ;
180Vac-260
Vac
230V ;
180Vac-260Va
c
Nominal
Frequency
50Hz 50Hz 50Hz 50Hz 50Hz 50Hz
SPH&SPH TL
BL-UP Rated
input / output
current
13.5/13.5
A&13.5/13.5
A
13.5/16A&16
/16 A
13.5/17.5
A&17.5/17.5
A
13.5/20
A&/20/20 A
13.5/22
A&22/22 A
13.5/27
A&27/27 A
Max inrush peak
current
10A(5mS)
