3. Press the power button. The power button flashes red. Once the scanner is switched on and connected to
the Internet, the power button shows a steady green light. In case the light turns purple, the scanner could
not connect to the Internet. If this happens, you can do the initial setup using WLAN (see chapter 7.2).
4. Open the browser in your computer or tablet and type the following in the browser’s address field:
http://mgu-00001-XXXXXX.device.grundium.net
Note: Make sure that the browser is using http instead of https at this phase.
5. Replace the X’s with the scanner’s serial number (six digits) found on the label at the bottom of the
scanner or on the sticker attached to quick start guide (Image 4).
6. Follow the instructions on your computer or tablet to register a new user account or to use an existing
one. The account enables you to use the scanner.
You can also create a new team. A team enables you to share the scanner with other team members. If you
want to join an existing team, ask someone from the team to add you. See instruction for Create a new
team.
7.2 FIRST USE WITH A WLAN CONNECTION
To use a WLAN connection, you need:
• The name of the WLAN (SSID) provided by the scanner and your password. These are found on the label at
the bottom of the scanner or on the sticker attached to quick start guide.
• The name and password of the WLAN to which the scanner connects for an Internet access. Contact your
system administrator for assistance, if needed.
Tip: You can use your smart phone hotspot feature to create WLAN Internet connection
1. Attach the power cable to the scanner and plug the cable in a wall outlet. The power button shows a
breathing green light.
2. Press the power button. The power button flashes red. Once the scanner is switched on and acts as a
WLAN access point, the power button shows a steady purple light.
3. Open the WLAN settings in your computer or tablet and search for available networks.
4. Connect to “Ocus_XX” WLAN (XX is replaced by the two last digits of the scanner’s serial number). The
password for the scanner WLAN can be found on the label at the bottom of the scanner or on the sticker
attached to quick start guide (Image 4). If the computer asks for a PIN code instead of a password, switch to
using a passphrase.
5. Open the browser in your computer or tablet and type the following in the browser’s address field:
http://www.grundium.net
Note: Make sure that the browser is using http instead of https at this phase.
6. Follow the instructions on your computer or tablet to connect the scanner to a WLAN that has access to
the Internet.
