4. Installation
18 PNEG-2343 U-Trough Free Flow Unloading System
3. Install the bin wall flange as shown in Figure 4C.
Figure 4C
4. Secure the bin wall flange with self-tapping screws (33) as shown in Figure 4D.
Figure 4D
Ref # Description Ref # Description
53 Bin Plate Upper 55 Bin Plate Lower
54 Foam Sealing Strips
Ref # Description
33 Self-Tapping Screw
53
54
55
33
33
33
