DA98D User Manual
57
110SJT—M040D 19
0
-0.013
95
0
-0.035
186(237) 241(292)
110SJT—M060D 19
0
-0.013
95
0
-0.035
212(263) 267(318)
Note: The LB and L value in the bracket is the length of motor with electricity-losing brake of the
corresponding specifications.
(2) Figuration and installment dimension for SJT series of 130-stand model AC servo
motors
Specifications D(mm) N(mm) LB(mm) L(mm)
130SJT—M040D 22
0
-0.013
110
0
-0.035
168(227) 225(284)
130SJT—M050D 22
0
-0.013
110
0
-0.035
168(227) 225(284)
130SJT—M060D 22
0
-0.013
110
0
-0.035
190(249) 247(306)
130SJT—M075D 22
0
-0.013
110
0
-0.035
190(249) 247(306)
130SJT—M100B 22
0
-0.013
110
0
-0.035
208(267) 265(324)
130SJT—M100D 22
0
-0.013
110
0
-0.035
208(267) 265(324)
130SJT—M150B 22
0
-0.013
110
0
-0.035
238(297) 295(354)
130SJT—M150D 22
0
-0.013
110
0
-0.035
248(307) 305(364)
Note: The LB and L value in the bracket is the length of motor with electricity-losing brake of
the corresponding specifications.
(3) Figuration Drawing for DST series of 110-stand model AC servo motors
