Weighing
Menu
Start
Scale
KG
ExitTa r e
Scale
248.0 kg
1. Always reset the GH3+ scale module before weighing takes place, see
section entitled “Resetting the unit”.
2. Position the lifting sling on the user and attach it to the lifting hanger.
3. Lift the user with care.
4. Park the hand control on the lifting hanger.
5. Select “Menu” using the function key located immediately below the
display and then select until the “Scale” menu appears in the display.
6. Then select “Start”.
7. When the sling and the user are at rest and hanging freely, the current
weight can be read on the display. (The weight can be read to an accuracy
of 1 decimal place).
8. Select “Exit” to return to the main menu.
Note:
The display in the hand control switches o󰀨 automatically after use
(approx. 8 min.)
