GPP Series User Manual
42
Connection
Voltage/Cur
rent Rating
GPP-1326：32V/6A x 1
GPP-2323/3323/4323：
CH1/CH2: 32V/3A x 2
CH3:1.8V/2.5V/3.3V/5V/5A x 1 (GPP-3323)
USB Port Output：3A (GPP-3323)
5V/1A x 1 (GPP-4323)
CH4:15V/1A x 1
Setting
1. Press F4 or F5 button for operating the
corresponding Independent to enter the
Independent function.
2. For setting opertation of parameter, refer to
page 37.
Output
The independent button ON/OFF of each
channel is available, while All ON/OFF button
is available for all channels.
+ - + - + - + -
CH3
Load
CH2
Load
CH1
Load
CH4
Load
