GW Instek GPP-2323 User Manual

GPP Series User Manual
48
Others
OPP： Fixed 50W of single
channel(GPP-1326:100W), non-
revisable
OVP/OCP： indentical to Source
Parameter
setting
Vset
Press F4 or F5 button for operating
the corresponding (CV) mode
followed by F1 button (Vset). The
voltage setting area on LCD will be
activated and appears
(red font color with the underline
indicator).
(a) number pad (0-9,.) input; press
unit button F1 (V) or F2 (mV) button
to confirm:
Input 6.54V:
(b) Step input: Press the
left or right arrow
buttons to select high and
low level that require
fine tune (underline
below the corresponding
number value), and scroll
the scroll wheel to
increase or decrease
setting value.
Iset
Press F4 or F5 button for operating
the corresponding (CC) mode
followed by F1 button (Iset). The
current setting area on LCD will be
activated and appears (red
