GW Instek GPP-4323 - Status Commands

GPP Series User Manual
166
Function
Queries the controlled channel (channel) from the
trigger output of the specified data line.
Example
:TRIGger:OUT:SOURce? D0
Returns the controlled channel from the trigger
output of D0 data line.
Status Commands
Command
STATUS?
Function
Returns the Status .
Return
parameter
8 bits in the following format
Note
Bit 6,7: 11=19200bps, 38400bps, LAN, GPIB
Example
STATUS?
Command
:STATus:PRESet
Function
Clears the operation event enable registers, the
measurement event enable registers and the
questionable event register, The unit will then
return to the default settings status.
Example
:STATus:PRESet
Command
:STATus:OPERation[:EVENt]?
Function
Read the operation event register.
Example
:STATus:OPERation?
Reads the operation event register.
