GW Instek GPP-4323 - Set Monitor

GPP Series User Manual
72
Set Monitor
Parameter
Description
Voltage
Set condition of monitor of voltage.
Current
Set condition of monitor of current.
Power
Set condition of monitor of power.
Stop
Type
Set status after halt. 3 types are
available, output disable, content
notice and audible alarm.
Select
To confirm if
voltage/current/power is selected as
monitor object. White font stands for
selected, while gray font represents
not selected.
Parameter
Setting
Voltage
Press the Advance key on control
panel. Select the F4 (Monitor)
function followed by pressing the F1
(Voltage) button to enter the voltage
setting.
1. Press the F1 (Set) button. The
setting on LCD is activated and
appears in red fond color. Use
number pad to set the parameters
directly; or use arrow keys along
with scroll wheel to complete the
setting.
2. Press the F4 (Define) button to
define terminated condition.
3. Press the F5 (Logic) button to
define logical pattern of other
conditions.
