GW Instek GPP-4323 User Manual

BASIC OPERATION
41
current displays
in red CC.
OVP/OCP
OVP/OCP displays in white
when OVP is not in activation.
OVP/OCP displays in red and
output is off when OVP is
activated.
OVP/OCP displays in gray when
OVP/OCP functions are off.
Independent Output Mode
Description
Each channel within the models GPP-
1326/2323/3323/4323 series is apart from one
another and capable of operations including
independent setting and individual output, etc.
Connection
+ - + - + - + -
CH3
Load
CH2
Load
CH1
Load
CH4
Load

GW Instek GPP-4323 Specifications

General

Number of Outputs	4
Ripple and Noise (CC)	≤ 3 mArms
Output Voltage	0 to 32 V
Output Current	0 to 3 A
Ripple and Noise (CV)	≤ 1 mVrms
Load Regulation (CV)	≤0.01% + 3mV
Load Regulation (CC)	≤0.2% + 3mA
Line Regulation (CV)	≤ 0.01% + 2 mV
Line Regulation (CC)	≤0.2% + 3mA
Display	4.3 inch LCD
Interface	USB, RS232
Operating Temperature	0 to 40 °C
Storage Temperature	-10 to 70 °C
