GPP Series User Manual
52
to set the parameters directly and
then press the F1 (Done) button to
confirm; or use arrow keys along
with scroll wheel to complete the
setting.
End State
Under the Sequence function, press
F1 (Set) button followed by selecting
F4 (End State), and 2 statuses
Last/Output off will appear in turn
on LCD . The one
displaying is what’s called the
current status.
Operation
ON/OFF
Press the F5 (SEQ.On) button. When
the output is on, the Output key will
light up. When the output is off, the
Output key will not be lit. SEQ will
appear in the status area (yellow for
CH1 only, blue for CH2 only, while
white for both on).
CAUTION
If the channel has been in Output
ON before Sequence function, the
status remains unchanged until
SEQ.On so that Sequence starts to
output.
Set Group Parameter
Description
Each Group consists of Voltage, Current and
Time. Therefore, properly confirm parameter of
each group is correct before setting Sequence
output.
Parameter
Description
No.
Voltage
Group number. Maximum 2047
Voltage setting of each group.
