GPP Series User Manual
42
Voltage/Cur
rent Rating
GPP-1326：32V/6A x 1
GPP-2323/3323/4323：
CH1/CH2: 32V/3A x 2
CH3:1.8V/2.5V/3.3V/5V/5A x 1 (GPP-3323)
USB Port Output：3A (GPP-3323)
5V/1A x 1 (GPP-4323)
CH4:15V/1A x 1
Setting
1. Press F4 or F5 button for operating the
corresponding Independent to enter the
Independent function. 2. For
setting opertation of parameter, refer to page 37.
Output
The independent button ON/OFF of each
channel is available, while All ON/OFF button
is available for all channels.
Tracking Series and Tracking Parallel Modes
Descri
ption
Tracking series operation doubles the Voltage
capacity of the GPP-2323/3323/4323 by internally
connecting CH1 (Master) and CH2 (Slave) in series
and combining the output to a single channel. CH1
(Master) controls the combined Voltage output level.
