GPP Series User Manual
80
Key Function Description
Input/Output Mode:
Key
Function
Operation Result
F1
Data
Line
Select object to be set from D0 to F4
F2
Enabl e
Set to Enable or Disable function of the port
F3
Mode
Set which mode to adopt: Input Mode or
Output Mode
F4
Channel
Select corresponding channel: F1(CH1), F2
(CH2), F3 (CH3), F4 (CH4)
F5
More
F6
Return
F5 (More) under Input Mode setting:
Key
Function
Operation Result
F1
Type
Select trigger type: F1(RiseEdge), F2
(FallEdge), F3 (Hi-Level), F4 (Lo-Level), ,
F5(States Input)
F2
Response
Set result after trigger response:
F1(Output) sets as ON, OFF or reverse
Toggle
F2 (PWR.Mode) sets channel as power mode
F3 (Load Mode) set channel as load
CV/CC/CR mode
F4(Track Mode) sets tracking mode of
CH1/CH2
F3
Sensitivity
Set sensitivity of trigger: High/Middel/Low
F4
F5
F6
Return
