BASIC OPERATION
81
F5 (More) under Output Mode setting:
Key
Function
Operation Result
F1
Condition
Set response type: F1(Output), F2 (Voltage),
F3 (Current), F4 (Power), F5 (Auto)
F2
Polarity
Set the polarity of output signal
F3
F4
F5
State Out.
Enable or disable the state output
F6
Return
Description
Operation
Press the System key on control panel. Select the
F1 (Interface) function followed by pressing the
F5 (Control I/O) button to enter the setting of
external I/O.
Press the F1 (Data Line) button. Select required
data line from D0 through D5: F1(D0), F2(D1) ,
F3(D2) , F4(D3) , F5(D4).
Press the F2 (Enable) button to set this terminal
as input or output function. This button enables
Trigger in or Trigger out to be selected in turn.
Press the F3 (Mode) button to set this terminal as
input or output function. This button enables
Input Mode or Output Mode to be selected in
turn.
Press the F4 (Channel) button to activate the
function of this terminal. This button enables
Enable or Disenable to be selected in turn.
Key F5
(More)
After pressing the F3 (Mode) button, Trigger in
and Trigger out will bring about different results
individually. Refer to the table above for details.
