GPP Series User Manual
22
Unlock
Press the F6 butto
n to unlock,
which can disable rem
ote
control and return to pa
nel
operation.
T
erminals
CH1 terminal
Power output ter
minal or load
input terminal
CH2 terminal
Power output termi
nal or load
input terminal
CH3 terminal
Power output termi
nal
Power output termi
nal (GPP
-
3323 only)
Warning: The output c
urrent from t
he 2 terminals sh
ould
Not exceed 5A
for GPP-
3323.
CH4 terminal
Power output termi
nal
GND terminal
Ground terminal
21
23
